Chapter 24
Observations
24.4.3.13.11 Beginning and Ending of Precipitation
At designated stations, the beginning and ending times of precipitation are coded in the following format: the type of precipitation, followed by either a B for beginning or an E for ending, and the time of occurrence. No spaces are coded between the elements. The coded times of the precipitation start and stop times are found in the remarks section of the next METAR. The times are not required to be in the SPECI. The intensity qualifiers are coded. For example, if rain began at 0005 and ended at 0030, and then snow began at 0020 and ended at 0055, the remark would be coded RAB05E30SNB20E55. If the precipitation was showery, the remark is coded SHRAB05E30SHSNB20E55. If rain ended and snow began at 0042, the remark would be coded as RAESNB42.
24.4.3.13.12 Beginning and Ending of Thunderstorms
The beginning and ending times of thunderstorms are coded in the following format: the thunderstorm identifier TS, followed by either a B for beginning or an E for ending, and the time of occurrence. No spaces are between the elements. For example, if a thunderstorm began at 0159 and ended at 0230, the remark is coded TSB0159E30.
24.4.3.13.13 Thunderstorm Location
Thunderstorm locations are coded in the following format: the thunderstorm identifier TS, followed by the location of the thunderstorm(s) from the station, and the direction of movement, when known. For example, a thunderstorm southeast of the station and moving toward the northeast is coded TS SE MOV NE.
24.4.3.13.14 Hailstone Size
At designated stations, the hailstone size is coded in the following format: the hail identifier GR, followed by the size of the largest hailstone. The hailstone size is coded in ¼ in increments. For example, GR 1 3/4 would indicate that the largest hailstones were 1¾ in in diameter. When small hail with a size less than ¼ in is occurring, the hailstone size is reported in the remarks as GR LESS THAN 1⁄4 in.
24.4.3.13.15 Virga
At designated stations, virga is coded in the following format: the identifier VIRGA, followed by the direction from the station. The direction of the phenomena from the station is optional (e.g., VIRGA or VIRGA SW).
24.4.3.13.16 Variable Ceiling Height
The variable ceiling height is coded in the following format: the identifier CIG, followed by the lowest ceiling height recorded, V denoting variability between two values, and ending with the highest ceiling height. A single space follows the identifier with no other spaces between the letter V and the lowest/highest ceiling values. For example, CIG 005V010 would indicate a ceiling is variable between 500–1,000 ft.
24.4.3.13.17 Obscurations
Obscurations, surface-based or aloft, are coded in the following format: the weather identifier causing the obscuration at the surface or aloft, followed by the sky cover of the obscuration aloft (FEW, SCT, BKN, OVC) or at the surface (FEW, SCT, BKN), and the height. Surface-based obscurations have a height of 000. A space separates the weather causing the obscuration and the sky cover; no space is between the sky cover and the height. For example, fog hiding 3/8 to 4/8 of the sky is coded FG SCT000; a broken layer at 2,000 ft composed of smoke is coded FU BKN020.
24.4.3.13.18 Variable Sky Condition
Variable sky condition remarks are coded in the following format: the two operationally significant sky conditions (FEW, SCT, BKN, and OVC), separated by spaces, and V denoting the variability between the two ranges. If several layers have the same condition amount, the layer height of the variable layer is coded. For example, a cloud layer at 1,400 ft varying between broken and overcast is coded BKN014 V OVC.
24.4.3.13.19 Significant Cloud Types
At manual stations, significant cloud type remarks are coded in all reports.
