Automation systems provide an interface allowing the pilot to set a desired aircraft state. The system takes pilot input and aircraft information into account, develops a logical solution, and acts to fulfill the programmed objectives without continuous input from the pilot. When used properly, automation can reduce workload, enhance situational awareness, and allow the pilot to focus more attention on the aircraft flight path. Aircraft automation designs range from basic control of one system to complex integration of many systems.

At the start of the age of automation, engineers designed automation into individual systems. For example, a pilot might hold a switch and monitor an indicator to obtain a desired flap setting in an aircraft equipped with electric flaps. Automation of this system included a series of detents for the flap switch such that the pilot could select the desired flap setting. The system sensed the input and automatically positioned the flaps as set by the pilot. This system reduced the time and attention needed to set flaps.

With the advent of computers, networks, and conversion between analog and digital signals, it became possible to control many functions at the same time. These systems, available for some time in transport category aircraft, are now widely available in general aviation aircraft. This chapter discusses how the use of these systems can affect safety.

Some automation technologies include:

The use of automation comes with certain cautions. Automation should reduce workload, but in some instances, it may create more work, confusion, and contribute to errors. At other times, automation may lull pilots into complacency. Pilots who consistently rely on an autopilot for flight path management may experience degraded ability to fly manually when required to do so. For example, when flying in icing conditions, an automated system may make control inputs to compensate for ice accumulation. However, if the system exceeds its limits, it could disconnect and leave the aircraft in an undesired state. A pilot who has become unaccustomed to manual flight may not be prepared to handle the situation.

Reprogramming tasks that occur unexpectedly can trigger pilot errors, which may result in flight path deviations or other undesired aircraft states. Pilots should anticipate the need to fly manually and be prepared to maintain the desired flight path when manual control becomes necessary.

Pilots who use automation should train and practice for various scenarios in order to avoid becoming overly distracted when making a programming change or correcting an error. Being startled or confused by a programming mistake or automation malfunction occurs less often when the pilot has the capability for transition to manual flight. If the automation is not functioning according to expectation, the pilot may reduce the level of automation, fly manually, and take time to resolve the condition.

Pilots choose the level of flight path automation. Risk management strategies suggest using automation as an aid to manage workload rather than to compensate for lack of proficiency. A balance of automated and manual flight that takes workload and proficiency into consideration gives the pilot greater opportunity to monitor the flight path and aircraft state.

Choosing the appropriate level of automation for the task and adjusting as circumstances dictate is essential to effective use of automation. One of the most common errors is failing to move to lower levels of automation suitable to a changing environment.

For example, a pilot may track an approach course adequately using manual control inputs. However, the pilot may also need to listen to and record the Automatic Terminal Information Service (ATIS), retrieve and load an instrument approach procedure, prepare for the instrument approach, and accomplish the appropriate checklists. These tasks will increase workload and divert pilot attention from monitoring and controlling the flight path. If using an autopilot to track the approach, the automation performs the control inputs and allows the pilot to complete other tasks quickly and efficiently.

Continuing the scenario above, the pilot loads the instrument approach and decides to remain on autopilot. However, after the aircraft passes the initial approach fix, ATC cancels the approach clearance. ATC provides vectors and tells the pilot to expect to hold. In this situation, the pilot may select basic autopilot modes that control heading and altitude in order to comply with the assignment from ATC. The lower level of automation allows the pilot to program and configure the aircraft for an unexpected change while keeping the flightpath and aircraft state under control.

Pilots may sometimes choose to disengage the automation and fly the aircraft manually to maintain proficiency.

Regardless of the level of automation, pilots should consider the following series of steps: [Figure 7-2]
